Feature |
Specifications |
Engine |
23 hp Kohler® KT730 |
Horsepower |
23 |
Cylinders |
2 |
Oil Capacity |
2.0 qt (1.9L) |
Drive System |
Hydro-Gear® ZT-2800 |
Hydro Oil Cooler |
N/A |
Fuel Capacity |
5 Gallon |
Steering Control |
Joystick, Twin Lever |
Stand-up Deck |
Standard |
Pivoting Front Axle |
N/A |
Roll-Over Protection |
N/A |
Tires, Rear |
20x10-10, 20x12-10 |
Tires, Front |
13x6.5-6 |
Turning Radius |
Zero-Turn |
Ground Speed (Forward/Reverse) |
7.5 mph/4 mph |
Length |
79" |
Height : top of seat back |
45" |
Height : top of ROPS extended |
N/A |
Height : top of ROPS folded |
N/A |
Width, Tractor (outside rear tires) |
47", 48" |
Width, Deck w/ Chute |
58", 67", 74" |
Width, Deck Chute Up |
50", 55", 62" |
Cutting Width |
48", 54", 60" |
Cutting Height |
1.5" - 4.5" (1/4" increments) |
Deck Construction |
Welded 12 Gauge Steel Deck with 12 Gauge Strategic Reinforcements |
Deck Engagement |
Electric, Warner® |
Blade Length |
17", 18.375", 21" |
Spindle Assembly |
Cast aluminum housing; 1" diameter shaft; maintenance free |
Blade Tip Speed, approx. |
18,000 fpm |
Weight |
688 lbs, 700 lbs, 722 lbs |
Seat |
Adjustable, High Back, Deluxe Bucket Seat |
Other Standard Features |
Hour Meter, Electric Start, Arm Rest, Cup Holder, Hitch Plate |
