Feature |
Specifications |
Engine |
23.5 hp Kawasaki® FX730V, 25 hp Kohler® ZT740 (Joystick Steering Only) |
Horsepower |
23.5, 25 |
Cylinders |
2 |
Oil Capacity |
2 qt (1.9 L), 2.2 qt (2.1 L) |
Drive System |
Hydro-Gear® ZT-3400 |
Hydro Oil Cooler |
N/A |
Fuel Capacity |
7 Gallon |
Steering Control |
Joystick, Twin Lever |
Stand-up Deck |
Standard |
Pivoting Front Axle |
Standard |
Roll-Over Protection |
Standard |
Tires, Rear |
22x11-10 |
Tires, Front |
13x6.5-6 |
Turning Radius |
Zero-Turn |
Ground Speed (Forward/Reverse) |
9 mph/5 mph |
Length |
79" |
Height : top of seat back |
N/A |
Height : top of ROPS extended |
75" |
Height : top of ROPS folded |
49" |
Width, Tractor (outside rear tires) |
49" |
Width, Deck w/ Chute |
65", 73" |
Width, Deck Chute Up |
53", 61" |
Cutting Width |
52", 60" |
Cutting Height |
1.5" - 5" (1/4" increments) |
Deck Construction |
Laminated Welded 12 Gauge Steel Deck with 10 Gauge Strategic Reinforcements, including protective bullnose front & high impact anti-scalp rollers; 3/8" x 2" wear bar on trim edge |
Deck Engagement |
Electric, Ogura® |
Blade Length |
18.375", 21" |
Spindle Assembly |
Cast aluminum housing; 1" diameter shaft; maintenance free |
Blade Tip Speed, approx. |
18,000 fpm |
Weight |
930 lbs - 972 lbs |
Seat |
Suspension Seat with 2-1/4" Adjustable Travel, Vibration Isolators, Adjustable Seat Back Recline, Seat Back Pocket and Hinged Arm Rests (left hand arm rest not hinged on Joystick models) |
Other Standard Features |
Hour Meter, Electric Start, Arm Rest, Cup Holder, Front Step, Hitch Plate |
